Power-down data protection is a critical feature in many system devices, ensuring that important data is not lost when the power supply is interrupted. This paper introduces an improved method for power-down data protection using a microcontroller-based circuit design. The approach leverages the LM358 as a voltage comparator to trigger a write operation to EEPROM when the system detects a power failure.
Currently, two main methods are used for power-down data protection: one involves using a large backup battery to maintain system operation after power loss, while the other stores critical data in non-volatile memory such as EEPROM or Flash without requiring a battery. The first method is bulky and costly, while the second has limitations on the number of erase/write cycles. To overcome these issues, this paper proposes a more efficient solution by combining a capacitor and inductor with a microcontroller to provide temporary power during a power outage, allowing the system to safely store data in EEPROM before shutting down.
The circuit design uses a simple RLC circuit to sustain power for a short period after the main power is removed. The LM358 monitors the voltage level, and when it drops below a certain threshold, it triggers an interrupt in the microcontroller. This interrupt initiates the process of erasing and writing data to the EEPROM, ensuring that critical information is preserved.
The software design includes a main program and an interrupt service routine. When the system is powered down, the interrupt is activated, and the microcontroller performs the necessary operations to save the current state. After power is restored, the stored data is retrieved, allowing the system to resume from where it left off.
This method improves the reliability and longevity of the EEPROM while keeping the hardware design simple and cost-effective. It has been successfully applied in a 2D motion control platform, where X and Y-axis positions are saved and restored automatically. The design is also flexible, allowing for multiple data storage and retrieval operations through loop statements.
Overall, this approach offers a practical and efficient solution for power-down data protection, making it suitable for a wide range of applications.
