Electric thermostat blast drying oven

The nine operating sequences are not reversed!

1.

Electric thermostat blast drying oven

A control switch should be installed in the power supply line for this unit, and use a wire twice as thick as the grounding wire to ensure safety.

2.

Electric thermostat blast drying oven

Place the oven indoors in a dry and level area. Avoid using it near other fixtures or objects that may interfere with its operation.

3.

Electric thermostat blast drying oven

Once everything is ready, place the sample inside, close the door, insert a thermometer into the top exhaust valve, and open the valve slightly. Then, connect the power and begin the process.

4.

Electric thermostat blast drying oven

Before powering on, check the electrical performance of the oven. Ensure there is no short circuit or leakage to avoid potential hazards.

5.

Electric thermostat blast drying oven

Connect the power supply and turn on the power switch. Set the temperature controller to your desired setting. When the green light is on and the red light is off, the internal heating begins. You can also activate the blower at this time for better air circulation.

6.

Electric thermostat blast drying oven

When the temperature stabilizes, you can turn off the heating switch, leaving only one set of heating elements active. This helps maintain a stable temperature and prevents fluctuations caused by excessive power usage.

7.

Electric thermostat blast drying oven

When the temperature reaches the set value, the controller will cut off the power, stopping the heating. If the temperature drops below the set point, the system will automatically restart. This cycle continues until the temperature stabilizes. It’s normal for the temperature to rise slightly due to residual heat, which usually settles within about 30 minutes. For digital controllers like XMTD-2301, you can adjust the fine-tuning knob to reduce any deviation between the set and actual readings. If the thermometer shows an incorrect temperature, you can manually adjust the controller settings to correct it.

8. Use electric heating constant temperature blast drying oven: Note:

1. This oven is not explosion-proof. Do not place volatile substances inside, as they may cause explosions or fires.

2. The average load capacity of the sample shelf is 10kg. Avoid overloading or placing items directly on the heat-dissipating plate, as this may affect hot air circulation.

1. Install a knife switch in the power line and ensure the oven is properly grounded.

2. Place the oven in a dry and flat indoor location.

3. Close the oven door and turn on the knife switch. Set the temperature controller to the required temperature. Once the green light is on and the red light is off, the internal heating starts. You can also turn on the blower for better air circulation. As the temperature rises, the display will show the measured temperature. When the set value is reached, the red light turns on, and the heating stops. The temperature gradually decreases, and when it falls below the set point, the system automatically restarts to maintain stability.

4. Before turning on the power, check the insulation resistance (it should be ≥0.5MΩ) and ensure the circuit is free from short circuits or open connections.

5. When the temperature stabilizes, you can turn off one set of heating elements to maintain a more stable temperature and reduce the impact of high power consumption on the system.

6. After running for half an hour, check if the thermometer reading matches the controller's display. If so, the oven is now in normal working condition.

7. During initial heating, the temperature may rise quickly due to thermal inertia. To prevent overheating during startup, it’s recommended to set the temperature to around 80% of the desired value initially. After a few cycles, adjust it to the final setting. This helps avoid large temperature spikes, especially for values up to 100°C, where the overshoot typically doesn’t exceed 10°C.

8. If the oven is used continuously, make sure to close the motor according to the test requirements to prolong its lifespan.

9. To observe the samples, use the double high-temperature resistant glass instead of opening the door frequently. Opening the door at high temperatures may cause the glass to crack due to sudden cooling.

10. Keep the oven clean at all times to ensure optimal performance and longevity.

11. Continuous operation should not exceed 12 hours.
